Error indexing a QGenericMatrix

Scheduled Pinned Locked Moved Solved General and Desktop
12 Posts 4 Posters 941 Views 3 Watching
  • Oldest to Newest
  • Newest to Oldest
  • Most Votes
Reply
  • Reply as topic
Log in to reply
This topic has been deleted. Only users with topic management privileges can see it.
  • V Offline
    V Offline
    viniltc
    wrote on last edited by viniltc
    #1

    Hi All,

    I do the following matrix manipulation:

     double RotMat[] = {
           2*(q0*q0)-1+ 2*(q1*q1), 2*(q1*q2 + q0*q3), 2*(q1*q3 - q0*q2),
           2*(q1*q2 - q0*q3), 2*(q0*q0)-1+ 2*(q2*q2), 2*(q1*q2 + q0*q1),
           2*(q1*q3 + q0*q2), 2*(q2*q3 - q0*q1), 2*(q0*q0)-1+ 2*(q3*q3)
       };
       QGenericMatrix<3,3,double> rotationmatrix(RotMat);


       double Acc[] = {
           a0, a1, a2
       };
       QGenericMatrix<1,3,double> accelmatrix(Acc);


       QGenericMatrix<1,3,double> Totmatrix = rotationmatrix*accelmatrix;


    where q0,q1,q2,q3 and a0,a1,a3 are realtime values from a sensor

    Then if I print TotMatrix my system is getting crashed! (screenshot)

    Any idea what might be the cause for this?

    Thank you

    Pl45m4P 1 Reply Last reply
    0
    • Christian EhrlicherC Offline
      Christian EhrlicherC Offline
      Christian Ehrlicher
      Lifetime Qt Champion
      wrote on last edited by
      #2

      @viniltc said in Error indexing a QGenericMatrix:

      Any idea what might be the cause for this?

      As always when you encounter a crash: Use a debugger and take a look at the backtrace to see where exactly it happens and why.

      Qt Online Installer direct download: https://download.qt.io/official_releases/online_installers/
      Visit the Qt Academy at https://academy.qt.io/catalog

      1 Reply Last reply
      1
      • JohanSoloJ Offline
        JohanSoloJ Offline
        JohanSolo
        wrote on last edited by
        #3

        I feel your accelmatrix is a row vector, which cannot be multiplied by a rotation matrix in that order. Either use a column vector or write accelmatrix * rotationmatrix (which would use the inverse rotation).

        `They did not know it was impossible, so they did it.'
        -- Mark Twain

        1 Reply Last reply
        0
        • V Offline
          V Offline
          viniltc
          wrote on last edited by
          #4

          @Christian-Ehrlicher @JohanSolo Thanks for your feedback.

          I feel like it's a problem of indexing.

             double a[] = {
                  0.5,0.8, 0.7
              };
              QGenericMatrix<3,1,double> A(a);


          What's the correct way to index each of A matrix's element?
          I get runtime error If I do this:

           qDebug() <<  "Element at 1,1:"<< A(1,1);


          It is pointing at qgenericmatrix.h

          template <int N, int M, typename T>
          Q_INLINE_TEMPLATE T& QGenericMatrix<N, M, T>::operator()(int row, int column)
          {
              Q_ASSERT(row >= 0 && row < M && column >= 0 && column < N); //------> error pointing here
              return m[column][row];
          }


          What I'm doing wrong here?

          1 Reply Last reply
          0
          • JohanSoloJ Offline
            JohanSoloJ Offline
            JohanSolo
            wrote on last edited by JohanSolo
            #5

            In C, C++ and other useful "real" languages, arrays and matrices are zero-indexed.

            `They did not know it was impossible, so they did it.'
            -- Mark Twain

            1 Reply Last reply
            2
            • V Offline
              V Offline
              viniltc
              wrote on last edited by
              #6

              @JohanSolo Thanks a lot :)

              1 Reply Last reply
              0
              • V viniltc

                Hi All,

                I do the following matrix manipulation:

                 double RotMat[] = {
                       2*(q0*q0)-1+ 2*(q1*q1), 2*(q1*q2 + q0*q3), 2*(q1*q3 - q0*q2),
                       2*(q1*q2 - q0*q3), 2*(q0*q0)-1+ 2*(q2*q2), 2*(q1*q2 + q0*q1),
                       2*(q1*q3 + q0*q2), 2*(q2*q3 - q0*q1), 2*(q0*q0)-1+ 2*(q3*q3)
                   };
                   QGenericMatrix<3,3,double> rotationmatrix(RotMat);


                   double Acc[] = {
                       a0, a1, a2
                   };
                   QGenericMatrix<1,3,double> accelmatrix(Acc);


                   QGenericMatrix<1,3,double> Totmatrix = rotationmatrix*accelmatrix;


                where q0,q1,q2,q3 and a0,a1,a3 are realtime values from a sensor

                Then if I print TotMatrix my system is getting crashed! (screenshot)

                Any idea what might be the cause for this?

                Thank you

                Pl45m4P Offline
                Pl45m4P Offline
                Pl45m4
                wrote on last edited by Pl45m4
                #7

                @viniltc said in Error indexing a QGenericMatrix:

                double RotMat[] = {
                2*(q0q0)-1+ 2(q1q1), 2(q1q2 + q0q3), 2*(q1q3 - q0q2),
                2*(q1q2 - q0q3), 2*(q0q0)-1+ 2(q2q2), 2(q1q2 + q0q1),
                2*(q1q3 + q0q2), 2*(q2q3 - q0q1), 2*(q0q0)-1+ 2(q3*q3)
                };

                This looks like quaternion multiplication :)
                You might want to have a look at QQuaternion which you can convert to QMatrix and QVector3D
                https://doc.qt.io/qt-5/qquaternion.html


                If debugging is the process of removing software bugs, then programming must be the process of putting them in.

                ~E. W. Dijkstra

                V 1 Reply Last reply
                3
                • Pl45m4P Pl45m4

                  @viniltc said in Error indexing a QGenericMatrix:

                  double RotMat[] = {
                  2*(q0q0)-1+ 2(q1q1), 2(q1q2 + q0q3), 2*(q1q3 - q0q2),
                  2*(q1q2 - q0q3), 2*(q0q0)-1+ 2(q2q2), 2(q1q2 + q0q1),
                  2*(q1q3 + q0q2), 2*(q2q3 - q0q1), 2*(q0q0)-1+ 2(q3*q3)
                  };

                  This looks like quaternion multiplication :)
                  You might want to have a look at QQuaternion which you can convert to QMatrix and QVector3D
                  https://doc.qt.io/qt-5/qquaternion.html

                  V Offline
                  V Offline
                  viniltc
                  wrote on last edited by
                  #8

                  @Pl45m4 Thanks a lot for your suggestion :)

                  I can't find an example of using QQuaternion class. I have a question, hope you can give me some feedback.
                  I have quaternion coming from the IMU in the form of w,x, y,z. (w is the scalar and others are vectors). Also acceleration vectors ax, ay, az. I need to rotate the accelerometer reading by the quaternion into the Earth frame of reference. How can I make use of QQuaternion class to perform this?

                  Pl45m4P 1 Reply Last reply
                  0
                  • V viniltc

                    @Pl45m4 Thanks a lot for your suggestion :)

                    I can't find an example of using QQuaternion class. I have a question, hope you can give me some feedback.
                    I have quaternion coming from the IMU in the form of w,x, y,z. (w is the scalar and others are vectors). Also acceleration vectors ax, ay, az. I need to rotate the accelerometer reading by the quaternion into the Earth frame of reference. How can I make use of QQuaternion class to perform this?

                    Pl45m4P Offline
                    Pl45m4P Offline
                    Pl45m4
                    wrote on last edited by Pl45m4
                    #9

                    @viniltc

                    This will rotate your vector or given axis by a given quaternion.
                    It's the same as using the rotation operator qvq*

                    QQuaternion q; // your Q
                    QVector3D vector(ax,ay,az);

                    QVector3D result = q.rotatedVector(vector);


                    https://doc.qt.io/qt-5/qquaternion.html#rotatedVector


                    If debugging is the process of removing software bugs, then programming must be the process of putting them in.

                    ~E. W. Dijkstra

                    1 Reply Last reply
                    1
                    • V Offline
                      V Offline
                      viniltc
                      wrote on last edited by
                      #10

                      @Pl45m4 Thanks a lot :)

                      1 Reply Last reply
                      0
                      • V Offline
                        V Offline
                        viniltc
                        wrote on last edited by
                        #11

                        @Pl45m4
                        I need to multiply a vector by the inverse quaternion. The Idea is to compensate gravity from acceleration vector. I did the following steps:

                        Step 1. Quaternion multiplication (v' = qvq*)
                        I did this:

                        QQuaternion q;
                        QVector3D aVector(ax,ay,az);
                        QVector3D qRotated = q.rotatedVector(vector); // this is v'


                        Step 2. Substarct gravity vector from the above rotated vector (v'' = qvq*-g) , g is gravity vector:

                        QVector3D g(0,0,1);
                        QVector3D result = qRotated-g; // this is v''


                        Step 3. I need to multiply the result by inverse quaternion (v''' = q-1 . v'' . q-1*)

                        I tried this (but I'm not sure if it's the right way to do it!):

                        QQuaternion quatinv= quat.inverted();
                        QVector3D noGRotated= quatinv.rotatedVector(result);


                        the noGRotated (or v''') should be the original acceleration measurement minus gravity. But there is something wrong with the calculation it seems, ideally if I take measurements while the device is stationary. No matter how the device is rotated, the acceleration measurements should be close to (0,0,0), but it is not in my case.

                        Do you see any issues in the Step 2 and 3 above?

                        Pl45m4P 1 Reply Last reply
                        0
                        • V viniltc

                          @Pl45m4
                          I need to multiply a vector by the inverse quaternion. The Idea is to compensate gravity from acceleration vector. I did the following steps:

                          Step 1. Quaternion multiplication (v' = qvq*)
                          I did this:

                          QQuaternion q;
                          QVector3D aVector(ax,ay,az);
                          QVector3D qRotated = q.rotatedVector(vector); // this is v'


                          Step 2. Substarct gravity vector from the above rotated vector (v'' = qvq*-g) , g is gravity vector:

                          QVector3D g(0,0,1);
                          QVector3D result = qRotated-g; // this is v''


                          Step 3. I need to multiply the result by inverse quaternion (v''' = q-1 . v'' . q-1*)

                          I tried this (but I'm not sure if it's the right way to do it!):

                          QQuaternion quatinv= quat.inverted();
                          QVector3D noGRotated= quatinv.rotatedVector(result);


                          the noGRotated (or v''') should be the original acceleration measurement minus gravity. But there is something wrong with the calculation it seems, ideally if I take measurements while the device is stationary. No matter how the device is rotated, the acceleration measurements should be close to (0,0,0), but it is not in my case.

                          Do you see any issues in the Step 2 and 3 above?

                          Pl45m4P Offline
                          Pl45m4P Offline
                          Pl45m4
                          wrote on last edited by
                          #12

                          @viniltc

                          Why you need the inverse of the resulting quaternion in step 3?
                          I've never done gravity compensation before, but I think it may works like suggested here:

                          https://stackoverflow.com/questions/18252692/gravity-compensation-in-accelerometer-data
                          https://stackoverflow.com/questions/12617200/remove-gravity-from-imu-accelerometer

                          There are also some papers dealing with this topic.

                          I would try to just subtract the gravity component (vector in Z - direction, let's say (0, 0, 9.81)) from your actual, accelerometer vector.

                          Is the result vector after step 2 looking correct?


                          If debugging is the process of removing software bugs, then programming must be the process of putting them in.

                          ~E. W. Dijkstra

                          1 Reply Last reply
                          1
