Populating a TabBar from a model

[mzimmers]

Hi all -

I'd like to create a TabBar with buttons derived from a C++ model. Each button would get its text from a property in the model.

Doable? Perhaps with addItem()?

Thanks...

[Bob64]

@mzimmers sorry, there is more than one thing going on here. My original suggestion was to use the Repeater which you have indeed followed. But then you asked about the model exposure in QML.

The usual way to expose a QAbstractListModel to QML is to override the data function. This returns a QVariant so whatever you return needs to be storable in a QVariant.

If you have a model that has a number of properties at each index, let's say "name", "age", "occupation", probably the most natural way to expose this is to override roleNames() and data():

class PersonListModel : public QAbstractListModel
{
    Q_OBJECT
public:
    PersonListModel (QObject* parent);

    enum MyRoles {
        NameRole = Qt::UserRole + 1,
        AgeRole,
        OccupationRole
    };
    ...
    private:
        QHash<int, QString> m_roles;

PersonListModel ::PersonListModel (QObject* parent) {
    // init roles
    m_roles[NameRole] = "name";
    m_roles[AgeRole] = "age";
    m_roles[OccupationRole] = "occupation";
    ...
}

// Override QAbstractItemModel function...
QHash<int, QByteArray> PersonListModel ::roleNames() const
{
    return m_roles;
}

// Override QAbstractItemModel function...
QVariant PersonListModel::data(const QModelIndex &index, int role) const
{
    if (!index.isValid())
        return QVariant();

    // For illustration only, the below assumes your actual data is stored
    // in something like a list of structs with `name`, `age` fields etc.
   // Obviously you can implement this in any way you like as long as you
   // can take an index and return the requested value

    if (index.row() < 0 || index.row() >= m_myModelData.size())
        return QVariant();

    switch (role) {
    case NameRole:
        return m_myModelData[index.row()].name;
    case AgeRole:
        ...
}

Now, the point about roleNames() in the above is that those strings that you associated with the enum values are what get exposed as property names on the QML side.

The QML does a lot of work for you given the above. In a delegate that references the model, you can directly refer to name, age etc., and under the hood, Qt will be calling data with the current index and the requested role ID and will be extracting the value from the returned QVariant into a QML-compatible type.

Relating this to your case, there are two approaches you could take. One is to "flatten" the model in a sense so that you don't need Zone as a type in this particular part of the QML code. So, what you might do is to define a ZoneNameRole mapped to "zoneName". You would implement your data() method something like this:

        case ZoneNameRole:
            return getZone(index.row()).name;
        ...

Then in your QML, you could assign your button text simply as:

Repeater {
    model: zoneModel
    delegate: TabButton {
        text: zoneName
    }
}

The other option is to expose Zone explicitly from the model as a role in its own right. This is possible because Zone is a Q_GADGET so is itself a type that interoperates with QML. The only thing you need to do if you aren't doing so already is to have a line like this in the header where you define Zone:

Q_DECLARE_METATYPE(Zone)

This allows a Zone to be stored in a QVariant.

With this approach your code might be more like this:

class ZoneModel : public QAbstractListModel
{
    Q_OBJECT
public:
    ZoneModel (QObject* parent);

    enum MyRoles {
       ZoneRole = Qt::UserRole + 1,
    };
    ...
    private:
        QHash<int, QString> m_roles;

ZoneModel ::ZoneModel (QObject* parent) {
    // init roles
    m_roles[ZoneRole] = "zone";
    ...
}

// Override QAbstractItemModel function...
QHash<int, QByteArray> ZoneModel ::roleNames() const
{
    return m_roles;
}

// Override QAbstractItemModel function...
QVariant ZoneModel::data(const QModelIndex &index, int role) const
{
    // ... check preconditions etc as before ...

    switch (role) {
    case ZoneRole:
        return getZone(index.row());
        ...
}

And in the QML:

Repeater {
    model: zoneModel
    delegate: TabButton {
        text: zone.name
    }
}

The official documentation is here:

https://doc.qt.io/qt-5/qtquick-modelviewsdata-cppmodels.html#qabstractitemmodel-subclass

[tzorake]

Hello. I read your requirements for desired widget, but didn't understand it completely. Can you do it more clear? I mean more description and visual presentation of it.

Is it something like this?

[Bob64]

@mzimmers you could use a Repeater in your TabBar with a delegate that creates a button. It could be driven by something based on QAbstractItemModel or QAbstractListModel.

You could mock it up using a QML ListModel to start with.

[mzimmers]

@Bob64 yep...that did the trick:

TabBar {
width: parent.width

Repeater {
    model: zoneModel
    delegate: TabButton {
        text: zoneModel.getZone(index).name
    }
}

This works just fine. I wonder, though...is there a way for me to eliminate the inner reference to zoneModel? I tried just model.getZone() but it says it's not a function. There's probably another way to form that line but I don't know what it is.

Thanks...

[piervalli]

This post is deleted!

[Bob64]

@mzimmers can you add a zoneName (or maybe just name) role to your model? That would automatically expose zoneName as a property available to your delegate and allow you to do text: zoneName in your button without even having to mention the index.

[mzimmers]

@piervalli I tried that:

Repeater {
    model: zoneModel
    delegate: TabButton {
        text: getZone(index).name
    }
}

Still yet runtime error not defined.

@Bob64 my ZoneModel class contains a list of Zone objects. In order to get the names of the individual zones, I use getZone() to return the zone, then get its name from one of its properties.

class ZoneModel: public QAbstractListModel
{
    Q_OBJECT
    ZoneList *m_list;
public:
    Q_INVOKABLE Zone getZone(int index);
...

class Zone {
    Q_GADGET
    QString m_name;
public:
    Q_PROPERTY(QString name MEMBER m_name)
    QString name() const { return m_name; }
...

[Bob64]

@mzimmers ok, I see. The approach you have taken is a way to expose a backend C++ model to QML but it probably isn't going to work as seamlessly on the QML side as the approach I mentioned, which essentially involves overriding roleNames and data.

Another approach is a hybrid, where you define a "zone" role and have data return a Zone corresponding to the requested index. Note that data returns a QVariant but it should be possible to arrange for your Zone type to be storable in a QVariant (it might already just work with it being a Q_GADGET - I forget the details at the moment and can't look them up). On the QML side, you should then be able to do something like text: zone.name.

[mzimmers]

@Bob64 said in Populating a TabBar from a model:

isn't going to work as seamlessly on the QML side as the approach I mentioned

I thought I was using the approach you mentioned. Where did I deviate from your suggestion?

Thanks...

[Bob64]

@mzimmers sorry, there is more than one thing going on here. My original suggestion was to use the Repeater which you have indeed followed. But then you asked about the model exposure in QML.

The usual way to expose a QAbstractListModel to QML is to override the data function. This returns a QVariant so whatever you return needs to be storable in a QVariant.

If you have a model that has a number of properties at each index, let's say "name", "age", "occupation", probably the most natural way to expose this is to override roleNames() and data():

class PersonListModel : public QAbstractListModel
{
    Q_OBJECT
public:
    PersonListModel (QObject* parent);

    enum MyRoles {
        NameRole = Qt::UserRole + 1,
        AgeRole,
        OccupationRole
    };
    ...
    private:
        QHash<int, QString> m_roles;

PersonListModel ::PersonListModel (QObject* parent) {
    // init roles
    m_roles[NameRole] = "name";
    m_roles[AgeRole] = "age";
    m_roles[OccupationRole] = "occupation";
    ...
}

// Override QAbstractItemModel function...
QHash<int, QByteArray> PersonListModel ::roleNames() const
{
    return m_roles;
}

// Override QAbstractItemModel function...
QVariant PersonListModel::data(const QModelIndex &index, int role) const
{
    if (!index.isValid())
        return QVariant();

    // For illustration only, the below assumes your actual data is stored
    // in something like a list of structs with `name`, `age` fields etc.
   // Obviously you can implement this in any way you like as long as you
   // can take an index and return the requested value

    if (index.row() < 0 || index.row() >= m_myModelData.size())
        return QVariant();

    switch (role) {
    case NameRole:
        return m_myModelData[index.row()].name;
    case AgeRole:
        ...
}

Now, the point about roleNames() in the above is that those strings that you associated with the enum values are what get exposed as property names on the QML side.

The QML does a lot of work for you given the above. In a delegate that references the model, you can directly refer to name, age etc., and under the hood, Qt will be calling data with the current index and the requested role ID and will be extracting the value from the returned QVariant into a QML-compatible type.

Relating this to your case, there are two approaches you could take. One is to "flatten" the model in a sense so that you don't need Zone as a type in this particular part of the QML code. So, what you might do is to define a ZoneNameRole mapped to "zoneName". You would implement your data() method something like this:

        case ZoneNameRole:
            return getZone(index.row()).name;
        ...

Then in your QML, you could assign your button text simply as:

Repeater {
    model: zoneModel
    delegate: TabButton {
        text: zoneName
    }
}

The other option is to expose Zone explicitly from the model as a role in its own right. This is possible because Zone is a Q_GADGET so is itself a type that interoperates with QML. The only thing you need to do if you aren't doing so already is to have a line like this in the header where you define Zone:

Q_DECLARE_METATYPE(Zone)

This allows a Zone to be stored in a QVariant.

With this approach your code might be more like this:

class ZoneModel : public QAbstractListModel
{
    Q_OBJECT
public:
    ZoneModel (QObject* parent);

    enum MyRoles {
       ZoneRole = Qt::UserRole + 1,
    };
    ...
    private:
        QHash<int, QString> m_roles;

ZoneModel ::ZoneModel (QObject* parent) {
    // init roles
    m_roles[ZoneRole] = "zone";
    ...
}

// Override QAbstractItemModel function...
QHash<int, QByteArray> ZoneModel ::roleNames() const
{
    return m_roles;
}

// Override QAbstractItemModel function...
QVariant ZoneModel::data(const QModelIndex &index, int role) const
{
    // ... check preconditions etc as before ...

    switch (role) {
    case ZoneRole:
        return getZone(index.row());
        ...
}

And in the QML:

Repeater {
    model: zoneModel
    delegate: TabButton {
        text: zone.name
    }
}

The official documentation is here:

https://doc.qt.io/qt-5/qtquick-modelviewsdata-cppmodels.html#qabstractitemmodel-subclass

[mzimmers]

@Bob64 first, thank you very much for the detailed answer. This very nicely corroborates and augments the Qt tutorial on this subject.

As it turns out, I had already reimplemented data(), setData() and roleNames() in my model. Everything was there; I just wasn't using it (properly) in my QML. This is my roleNames:

QHash<int, QByteArray> ZoneModel::roleNames() const
{
    QHash<int, QByteArray> zones;
    zones[NameRole] = "name";
    ...
    return zones;
}

and my data() (error checking removed):

QVariant ZoneModel::data(const QModelIndex &index, int role) const
{
    QVariant qv = QVariant();

    Zone item = m_list->zones().at(index.row());
    switch (role) {
    case NameRole:
        qv = item.name();
        break;
    default:
        qv = QVariant();
    }
    return qv;
}

(The additional level of indirection is that my actual list is defined in its own class (not the model class); again, this is from the tutorial.

So, all I had to do in my QML is:

Repeater {
    model: zoneModel
    delegate: TabButton {
        text: name
    }
}

Very easy, once one understands all the pieces of the model and how they work together.

Thank you again for the great explanation.
